An unmanned aerial vehicle (UAV), commonly known as a drone, as an unmanned aircraft system (UAS), or by several other names, is an aircraft without a human pilot aboard. The flight of UAVs may operate with various degrees of autonomy; either under remote control by a human operator, or fly autonomously based on pre-programmed flight plans.

Prashant Advanced Survey LLP have procured a DGCA type approved Survey Grade PPK UAV / Drone ‘Lookout VTOL’ from TAS, Bangalore, in 2018, with onboard PPK NovAtel GNSS for data capture and ‘Pix4D Professional Mapper’ software to produce accuracy upto 10 cm in X, Y, Z coordinates. This technology can be used to supplement the Mobile LiDAR data output in case of urban mapping projects, or highways projects having proposed bypass roads. This is also ideal for carrying out Topographic Survey of any land where speed and accuracy is of priority, with the rates comparable to primitive Electronic Total Station (ETS) method of survey.

Sr. Name of Equipment Make / model Numbers
1)

(DGCA Approved, UAV / Drone, PPK Survey Grade, NPNT, with Rotary wings)

LookOut VTOL Lite™- Model TALV2400_C

Mapper Series Industrial Unmanned Aerial System for Aerial Mapping, with onboard PPK / RTK NovAtel OEM7700 GPS / GNSS.

Bird Specification :

RPA Category : Micro, Quad Copter, NPNT
Physical Size 900 x 900 x 300 mm
Max all up weight including payload = 2 Kg
Operational Range Up to 2 Km, Max 8 Km.
Endurance Up to 30 Mins, Cruise Speed 10 m/s

Ground Control Station :

TAS GCS™ - Industrial Version
Tablet based Proprietary software
10- inch Android Tablet with case (Make: Iball)
433 MHz Telemetry communication up to 2 Kms

Sensor:

Calibrated A6000 Sony camera on 2-axis
stabilized platform RAW, RAW+JPEG
16 mm Fixed focal length lens APS-C (23.5mm x
15.6mm) Exmor® R CMOS sensor
24.3 Megapixels
Max Shutter Speed:1/160 Seconds
Pixel size 15.1 μm²
Colour depth - 24.1 bits
Autonomous camera triggering
Resolution GSD 2.4 cm / pixel

Accuracy : X & Y = 2 cm to 5 cm,
Z = 5 cm to 10 cm with PPK Novatel OEM 7700

Throttle Aerospace Systems Pvt. Ltd., Bangalore, India. (Made in India) 1
2)

UAV Data Processing Software :

Pix4d Professional Mapper Photogrammetric Software, Version 4.3.31

Pix4d 2
